EV Charger Installation in Western Chicagoland
Level 2 home charging installed the right way — proper panel-load assessment, code-compliant wiring, permits pulled, ComEd coordinated. Illinois EC License #062-012345, fully insured, Authorized Generac Dealer.
Charging at Home Should Just Work
Adding an EV to the household changes how your electrical system gets used. A Level 2 charger is a large, sustained load — often the second-biggest circuit in the house after the HVAC — and treating it like a plug-in appliance is how homeowners end up with tripped breakers, hot panel bus bars, and chargers that throttle themselves down to protect the wiring. A proper install starts with a real load calculation, not a guess.
We've been wiring residential systems in Western Chicagoland for over 25 years. Whether you're prepping for a first EV, adding a second charger for a two-EV household, or replacing a builder-grade outlet with a hardwired unit that can actually keep up, we install to code, pull permits, and leave a system your inspector, your utility, and your automaker's warranty department are all happy with.
What a Complete Installation Includes
Panel Load Assessment
Real load calculation per NEC 220 — we tell you whether your existing panel can support the charger you want, or whether a subpanel or upgrade is needed.
Dedicated 240V Circuit
New copper feeder sized to the charger's continuous rating, dedicated double-pole breaker, and proper conduit or Romex per the run.
Hardwired or NEMA 14-50
Hardwired install for chargers 40A and up (safer for continuous loads); NEMA 14-50 outlet where the charger is portable or supports it.
Permits & Inspection
We pull the DuPage County (or applicable jurisdiction) electrical permit and meet the inspector on-site.
Charger Mounting
Manufacturer-approved mounting height and location, indoor or weather-rated outdoor install, cord managed and out of driving lanes.
Commissioning & Handoff
First-charge verification, app pairing where applicable, and a walk-through of maintenance and safety features before we leave.
Our Installation Process
- 1
Free On-Site Assessment
We inspect the panel, measure the proposed cable run, review your vehicle and charger requirements, and confirm the cleanest install path.
- 2
Written Quote & Load Calculation
You get a fixed-price quote and, if requested, the load calculation showing exactly why the system will support the new circuit.
- 3
Permitting & Scheduling
We pull the permit, schedule a ComEd disconnect if a panel change is involved, and lock in an install date.
- 4
Installation Day
Typical single-visit installs run 3–5 hours. Panel-upgrade combined jobs run one day. Work areas are cleaned before we leave.
- 5
Inspection & First Charge
The county inspector signs off, we walk you through the charger, and you plug in your EV.
Why Homeowners Choose Us for EV Work
- Illinois EC License #062-012345 — every install is code-compliant and inspected
- Over 25 years of residential electrical work in Western Chicagoland
- Real load calculations, not seat-of-the-pants sizing
- Permits pulled and ComEd coordinated for you
- Hardwired installs available for 48A chargers where portables can't keep up
- Written fixed-price quotes — no surprise change orders
- Same crew you met at the assessment does the install
- Panel upgrades handled in-house when they're needed
Frequently Asked Questions
What's the difference between Level 1 and Level 2 charging?
Level 1 uses a standard 120-volt outlet and adds roughly 3–5 miles of range per hour — fine for plug-in hybrids but slow for a full EV. Level 2 runs on a dedicated 240-volt circuit and adds about 20–40 miles of range per hour, meaning most EVs recharge fully overnight. Nearly every new home EV installation we do in Western Chicagoland is Level 2.
Do I need a panel upgrade to install a home EV charger?
Not always. A typical Level 2 charger draws 32–48 amps, and many 200-amp panels have room. Homes on 100-amp service, older fuse boxes, or panels already near capacity from HVAC and other large loads usually need either a panel upgrade or a smart load-management device. We perform a load calculation during the on-site assessment so you know before we quote.
Where should the charger be installed?
The most common location is on the garage wall closest to your electrical panel — shorter wire runs mean lower cost. Detached garages, carports, and outdoor driveway installs are all possible; they just require weather-rated equipment and, for longer runs, larger-gauge wire. We'll walk the property with you and recommend the best combination of convenience and installed cost.
Which EV chargers do you install?
We install any UL-listed hardwired Level 2 charger, including units from ChargePoint, Wallbox, Enphase, Grizzl-E, Tesla, and the automaker-branded chargers shipped with new EVs. If you haven't picked a unit yet, we'll help you choose based on amperage, cord length, indoor/outdoor rating, and whether you want Wi-Fi and smart-scheduling features.
Do I need a permit in DuPage County?
Yes. EV charger installations require an electrical permit and a final inspection in DuPage County and every surrounding jurisdiction we serve. We pull permits, meet the inspector on-site, and handle any ComEd coordination if a panel change or service upgrade is required. Homeowners never contact the county or ComEd directly.
How long does installation take?
A straightforward Level 2 install with an accessible panel and a nearby garage location typically takes 3–5 hours in a single visit. Add a day if the panel needs an upgrade first, or if the run crosses to a detached garage. We give a firm timeline in the written quote after the on-site assessment.
Are there rebates or tax credits available?
ComEd periodically offers residential Level 2 charger and installation rebates, and the federal Alternative Fuel Vehicle Refueling Property Credit can offset installation cost for eligible properties. Programs change often; we'll flag any current offers during your quote so you can confirm eligibility with your utility and tax advisor.
Related Reading
Not sure whether your panel can handle a Level 2 charger alongside everything else? Our electrical panel upgrades page walks through when a 100A-to-200A upgrade is worth doing.
